Description
Stereo Power @ 8 Ohm 2 × 1550 Watts
Stereo Power @ 4 Ohm 2 × 2400 Watts
Stereo Power @ 2 Ohm 2 × 3100 Watts
Bridge Power @ 4 Ohm 6200 Watts
Amplifier Design
Amplifier Class Class H Circuit
2 Ohm Stable Yes
Frequency Response 20 Hz – 20 kHz (±0.5 dB)
Signal to Noise Ratio More than 105 dB
Damping Factor More than 700
Total Harmonic Distortion Less than 0.05%
Slew Rate 30 V/µs
Input Section
Input Sensitivity 0.775V / 1.0V / 1.4V Selectable
Input Impedance 20k Ohm Balanced / 10k Ohm Unbalanced
Connectors XLR Balanced Input
Crossover Filters Low Pass: 20 Hz – 500 Hz (12 dB/Oct)
High Pass: 20 Hz – 500 Hz (12 dB/Oct)
Filter Type Double Low Pass & High Pass
Crossover Slope 12 dB per Octave
Default Mode Full Range
Output Section
Speaker Output Connectors Speakon & Binding Post
Output Circuit Protection DC / Soft Start Protection
Cooling System
Cooling Intelligent Variable Speed Fans
Airflow Front to Rear
Protection System
DC Protection Yes
Thermal Protection Yes
Clip Limiter Yes
AC Voltage Protection Yes
Soft Start Protection Yes
Power Supply
Power Supply Type High Efficiency Toroidal Transformer
Operating Voltage 220 – 240V AC, 50 Hz
Build & Construction
Chassis Heavy Duty Metal Chassis
Front Panel Metal Front Panel
Mounting 19 Inch Rack Mountable
Components Industrial Grade Components
Finish Black Powder Coated
