Description
8Ω stereo power 2x900W
4Ω stereo power 2x1275W
2Ω stereo power 2x1700W
8Ω Bridge Mono power 2550W
4Ω Bridge Mono power 3400W
Signal Noise Ration(dB) ＞80dB
THD+N（8OHM 1KHZ IN 1/4 OUTPUT) ＜0.05%
Damping Factor(8OHM 1K) ＞1500
Slew Rate ＞20V/us
Input sensitivity 0.775v/1.0v/1.4v
Output Circuit Class H
Frequency Response(+/-0.1db) 20Hz-20kHz +-0.5dB
Input connectors(per ch.) 3-pin XLR, electronically balanced
Link connectors(per ch.） XLR, 3 pin male
Input Impedance 20kΩBALANCED-10kΩUNBALABCED
Output Connectors NEUTRIK
Amplifier Protection Protection of short circuit, open
circuit, overheat, overload, DC, super sonic frequency etc.
Transport Dimension(CM) 3U:67.5x57x19cm
Net Weight 35kgs
Gross Weight 37kgs
