| 8Ω stereo power |
2x1450W |
| 4Ω stereo power |
2x2225W |
| 2Ω stereo power |
2x2700W |
| 8Ω Bridge Mono power |
4050W |
| 4Ω Bridge Mono power |
5400W |
| Signal Noise Ratio (dB) |
＞80dB |
| THD+N（8OHM 1KHZ IN 1/4 OUTPUT) |
＜0.05% |
| Damping Factor(8OHM 1K) |
＞1500 |
| Slew Rate |
＞20V/us |
| Input sensitivity |
0.775v/1.0v/1.4v |
| Output Circuit |
Class H+ |
| Frequency Response(+/-0.1db) |
20Hz-20kHz +-0.5dB |
| Input connectors(per ch.) |
3-pin XLR, electronically balanced |
| Link connectors(per ch.） |
XLR, 3 pin male |
| Input Impedance |
20kΩBALANCED-10kΩUNBALABCED |
| Output Connectors |
NEUTRIK |
| Amplifier Protection |
Protection of short circuit, open circuit, overheat, overload, DC, super sonic frequency etc. |
| Transport Dimension(CM) |
3U:67.5x57x22.5cm |
| Net Weight |
40kgs |
| Gross Weight |
45kgs |
